SI Analytics·Titulación y electroquímica

TL 7750-TitriSoft

TL 7750-TitriSoft — sistema de titulación y electroquímica de SI Analytics (Measuring input analog pH/mV: pH/accuracy - 3.0 18.00 / 0.002 +/- 1 digit; mV/accuracy - 2000 2000/ 0.1 +/- 1 digit).

pH/accuracy - 3.0 18.00 / 0.002 +/- 1 digit; mV/accuracy - 2000 2000/ 0.1 +/- 1 digitMeasuring input analog pH/mV

A-connector for double platinum electrodes, connection: 2 x 4 mm - sockets, polarisation voltage variably adjustableMeasuring input A/KF

Connector for Pt 1000 / NTC 30 KOhm (connection: 2 x 4 mm - sockets)Temperatura

Cotizar o consultar

Descripción

Conoce el equipo

TL 7750-TitriSoft es un(a) sistema de titulación y electroquímica de SI Analytics, indicado para titulación potenciométrica, medición de ph y conductividad, análisis fisicoquímico. Especificaciones destacadas: Measuring input analog pH/mV: pH/accuracy - 3.0 18.00 / 0.002 +/- 1 digit; mV/accuracy - 2000 2000/ 0.1 +/- 1 digit; Measuring input A/KF: A-connector for double platinum electrodes, connection: 2 x 4 mm - sockets, polarisation voltage variably adjustable.

Aplicaciones ideales

Resuelve tu aplicación

Titulación potenciométrica

Medición de pH y conductividad

Análisis fisicoquímico

Especificaciones técnicas

Especificaciones
del TL 7750-TitriSoft

Measuring input analog pH/mV: pH/accuracy - 3.0 18.00 / 0.002 +/- 1 digit; mV/accuracy - 2000 2000/ 0.1 +/- 1 digit
Measuring input A/KF: A-connector for double platinum electrodes, connection: 2 x 4 mm - sockets, polarisation voltage variably adjustable
Measuring input temperature: Connector for Pt 1000 / NTC 30 KOhm (connection: 2 x 4 mm - sockets)
Measuring range temperature Pt 1000: -75 195 C
Measuring range temperature NTC 30 KOhm: -40 125 C
Interfaces: 3 USB (2 x USB-A and 1 USB-B), 2 RS-232-C and 1 x LAN
Interchangeable burettes: 5, 10, 20 ml or 50 ml intelligent interchangeable burette units
Resolution (Steps): 20.000 steps
Dosing accuracy according to DIN ISO 8655, part 3 - accuracy: 0.15 %
Dosing accuracy according to DIN ISO 8655, part 3 - precision: 0.05 - 0.07 %
Display: 3.5 inches - 1/4 VGA TFT graphic color display with 320 x 240 pixels
Housing material: Polypropylene
Front keyboard: Polyester coated
Material interchangeable burettes Valve: PTFE/ETFE
Material interchangeable burettes Cylinder: borosilikate glass 3.3 (DURAN)
Material interchangeable burettes hoses: FEP, blue
Dimensions: 15.3 x 45 x 29.6 cm (W x H x D)
Weight basic device: 2.3 kg
Weight complete device with interchangeable head: 3.5 kg
Ambient temperature operation and storage: +10 ... +40 C
Humidity according to EN 61 010, Part 1: max. relative humidity 80 % for temperatures up to 31 C, linear decrease down to 50 % relative humidity at a temperature of 40 C
Power supply: 100-240 V; 50/60 Hz, power input: 30 VA
Software: TitriSoft 3.5X
Magnetic stirrer: TM 235
